878 Sideflex Run Single Hinge Chain

Description

The 878 heavy duty sideflex run single hinge chain is a premium modular conveyor solution designed for high-load applications that require exceptional stability during directional changes. Built with a reinforced single-hinge structure and high-performance engineering plastics, the 878 series is specifically engineered to handle increased lateral stress and tensile loads in complex curved layouts. Its optimized link geometry ensures a smooth and consistent flow through horizontal curves, making it the ideal choice for demanding industrial environments such as automotive assembly, heavy logistics, and high-capacity bottling lines where reliability and durability are paramount.

Manufactured using high-precision injection molding and featuring cold-worked stainless steel pins, Hangzhou Ocean Industry's 878 heavy-duty chains provide maximum structural integrity and ultra-low friction operation. Every chain is produced under strict ISO9001 quality standards and undergoes rigorous testing to ensure it meets the extreme pull-out resistance and long-term service life required by global conveyor OEMs and system integrators.

Key Features

• Enhanced Side-Flexing Stability: the 878 series features a specialized link geometry that minimizes vibration and surging during curved transitions, ensuring that even the heaviest products maintain their orientation

• High-Tensile Single Hinge Design: engineered with a reinforced hinge eye and high-strength stainless steel pins, this chain offers superior load-bearing capacity and prevents elongation even under continuous, severe-duty operation

• Superior Wear Resistance: available in advanced low-friction acetal (POM) and high-impact nylon materials, the 878 chain is designed to withstand abrasive environments while protecting the conveyor’s wear strips

• Integrated Curve Retention: the link underside is engineered for secure track seating, providing excellent stability in curves and preventing chain lift-off or derailment under high speeds or lateral tension

• Chemical and Thermal Resilience: manufactured from materials that are resistant to industrial oils, cleaning agents, and thermal stress, making it suitable for foundry cooling lines and wash-down packaging areas

• Precision Machined Pin Bores: high-tolerance pin alignment ensures a perfect fit and consistent pitch, reducing mechanical noise and ensuring seamless interaction with drive sprockets

• Modular Customization: available in various standard widths and material grades, with optional side guards or surface patterns to match the specific requirements of your industrial conveying application

Application Range

• Automotive Manufacturing — curved conveying of transmissions, heavy chassis parts, and engine components

• Heavy-Duty Logistics — curved sorting systems and accumulation lines for oversized parcels and palletized freight

• Bottling and Canning — high-capacity curved routing of heavy crates, kegs, and multi-pack containers

• Metal and Foundry — transfer of heavy steel plates, castings, and machined components through cooling curves

• Construction Materials — stable curved handling of bricks, tiles, and heavy structural components

• Chemical Processing — curved transport of large drums, canisters, and industrial-grade containers

• Large Container Handling — high-speed accumulation and routing for 5-gallon containers and heavy-duty bins

• General Industrial Conveying — versatile and reliable curved flow for any high-load modular conveyor system

Trusted Manufacturer of 878 Heavy Duty Sideflex Roller Chains

Hangzhou Ocean Industry Co., Ltd. is a specialized manufacturer of 878 heavy duty sideflex run single hinge chains and advanced modular conveyor solutions, with products exported to Europe, North America, the Middle East, Southeast Asia, and other international markets since 2005. All 878 series chains are produced under ISO9001-certified quality management and are recognized by conveyor OEMs, system integrators, and heavy-industry end-users worldwide for extreme-load performance, reliable flexing efficiency, and competitive factory-direct pricing.

We offer complete OEM and ODM customization services — 878 heavy duty sideflexing chains can be manufactured to customer-supplied drawings, samples, or specific operational requirements. Contact our engineering team today with your drawings or requirements for a free quotation and technical consultation.
